Mercedes-Benz Vito Big Brake Kit Upgrade / TTSPORT Evolution Series ES6
A Mercedes-Benz Vito running shuttle or cargo duty spends a lot of time fully loaded, and that extra weight lands squarely on the brakes every time the vehicle slows down. The factory calipers and rotors weren't sized with that repeated load-and-stop cycle in mind, so this build swaps in a TTSPORT front-and-rear package built around the Evolution Series ES6 six-piston front caliper and the EP4 electromechanical four-piston rear caliper, both paired with 355 mm carbon-ceramic rotors and running behind the Vito's factory 18-inch wheels.
Vehicle & Kit Specs
| Item | Specification |
|---|---|
| Vehicle | Mercedes-Benz Vito, 18-inch wheels |
| Front caliper | TTSPORT Evolution Series ES6, two-piece forged aluminum, six-piston fixed caliper |
| Front rotor | 355 x 32 mm carbon-ceramic rotor |
| Rear caliper | TTSPORT EP4 electromechanical four-piston caliper with integrated electronic parking brake |
| Rear rotor | 355 mm carbon-ceramic rotor |
| Pads / hardware | Performance ceramic pads matched to the carbon-ceramic rotors, plus mounting bolts and fixing hardware |
The front axle carries the ES6 caliper, and its full factory spec sheet is below.
| Brake Caliper | |
|---|---|
| Series | Evolution Series |
| Model / Application | ES6 |
| Axle Position | Front |
| Piston Count | 6-piston |
| Piston Type | Two-piece heat-insulated pistons with dust boots |
| Piston Diameter | 27 mm × 2 / 32 mm × 2 / 38 mm × 2 |
| Caliper Dimensions | L 294 mm × W 155 mm × H 84 mm |
| Total Piston Area | 50.2 cm² per caliper, all pistons combined |
| Manufacturing Process | Two-piece forged aluminum body |
| Net Weight | 3.95 kg per caliper, without pads |
| Surface Finish | High-temperature gloss coating |
| Recommended Wheel Size | 18 in or larger |
| Recommended Rotor Size | Ø355–380 mm × 32 mm |
| Fitment & Installation | |
| Minimum Spoke Clearance (mm) | 99 |
| Caliper Mounting Type | Radial mount with vehicle-specific caliper brackets |
| Brake Line Fitting Type | Vehicle-specific fittings; caliper-side and chassis-side fittings vary by application |
Why It Works
A loaded Vito puts most of its braking demand on the front axle, which is why the ES6's staggered 27/32/38 mm pistons matter: the three sizes control how clamp load builds across the leading and trailing edges of the pad, instead of dumping all the pressure at one point. The two-piece forged aluminum caliper body flexes less than a stamped or thinner-wall housing under that same hydraulic load, so more of the pedal's pressure goes into clamping force instead of stretching the caliper.
Rear duty falls to the EP4, a four-piston electromechanical caliper that keeps the electronic parking brake built into the same unit rather than adding a separate parking-brake mechanism. Front and rear both run 355 mm carbon-ceramic rotors, which hold heat better and weigh less than a same-sized iron rotor — useful on a vehicle that's braking with real payload behind it, over and over, on a shuttle or delivery run.
- More thermal capacity front and rear for repeated stops under load
- Firmer, more direct pedal feedback from the forged ES6 caliper body
- More even front pad loading from the staggered piston sizing
- Reduced rotating and unsprung mass versus similarly sized iron rotors
- Electronic parking brake function retained through the EP4's integrated actuator
- Fits behind the Vito's factory 18-inch wheels once the 99 mm spoke clearance is confirmed
Installation Gallery
Fitment & Ownership FAQ
Does this TTSPORT brake kit fit every Mercedes-Benz Vito?
Will any 18-inch wheel clear the ES6 brake kit?
How is the electronic parking brake retained at the rear?
Can standard iron-rotor brake pads be used with these carbon-ceramic rotors?
What should be checked after the brake kit is installed?
Running a loaded Vito on a route that beats up your brakes? Confirm your wheel size and axle spec, then step up to the ES6/EP4 carbon-ceramic package.
