Mercedes-Benz C-Class Big Brake Kit Upgrade / TTSPORT EPB Series TT9040
Mercedes-Benz owners don't modify at the rate BMW or Audi drivers do, but the ones who do tend to go all-in — AMG-style body kits, sharper wheels, coilovers, and a brake upgrade to back it all up. This new-generation C-Class is one of those builds: a full front-six/rear-four TTSPORT big brake kit that replaces the stock stopping power with something that actually matches the car's new, more aggressive look.
The new C-Class shares its design language with the current E-Class and S-Class — a look that reads a little controversial on the bigger sedans but settles in nicely on the smaller C-Class body. The owner kept the exterior clean and let the brakes do the talking, tucking a front six-piston and rear four-piston TTSPORT setup behind 18-inch wheels.
Vehicle & Kit Specs
| Item | Specification |
|---|---|
| Vehicle | Mercedes-Benz C-Class (new generation), 18-inch wheels |
| Front caliper | TTSPORT TT9040 forged aerospace-grade aluminum, symmetric six-piston (stainless steel pistons) |
| Front rotor | 355 x 32mm curved-vane rotor, thermally treated with anti-rust/anti-corrosion coating |
| Rear caliper | TTSPORT TT6411 four-piston caliper paired with an integrated EPB electronic parking brake caliper |
| Rear rotor | 355 x 28mm rotor with Dacromet-coated, drilled/vented construction |
| Lines | TTSPORT stainless steel brake lines |
Why It Works
A forged six-piston front caliper does two things a stock single- or twin-piston sliding caliper can't: it clamps evenly across a wider pad face, and the forged aluminum body flexes far less under hard braking. Less flex means the pedal stays firm and predictable instead of going soft as heat and pressure build. The stainless steel pistons in the TT9040 also react faster and hold up better under sustained high temperatures, which keeps the bite consistent lap after lap or stop after stop.
The 355x32mm front rotor adds mass and surface area over the factory disc, giving the brakes more thermal capacity to absorb heat before fade sets in. The curved-vane design and thermal treatment help move air through the rotor faster, so heat gets pulled out between stops instead of building up.
- Forged monobloc front caliper resists flex for a firmer, more linear pedal
- Larger 355mm rotors front and rear add heat capacity versus the factory discs
- Rear caliper integrates an EPB unit, so the electronic parking brake still works with no separate actuator swap
The rear rotor's slotted, Dacromet-coated design is built to shed heat and resist thermal cracking, which the source specs at over 40% better crack resistance than an untreated disc — that matters most on a car that still relies on its rear brakes for daily parking duty via the EPB caliper. Because the EPB function is built into the TT6411 rear caliper itself, the parking brake install doesn't require any workaround on a car with an electronic system.
Installation Gallery
What wheel size does this TTSPORT big brake kit require on the Mercedes-Benz C-Class?
Does the rear kit keep the electronic parking brake working?
What's included on the front axle?
