Lexus NX Big Brake Kit Upgrade / TTSPORT Classic 5440
The Lexus NX is one of the brand's best-selling models, but the factory brake package under those handsome wheels is tuned for comfort, not for holding up under repeated hard stops. This build swaps in a TTSPORT Classic 5440 four-piston kit, front and rear two-piece rotors, and stainless lines — and it goes on without touching the car's original wheels.
The build: TTSPORT Classic 5440 four-piston calipers up front, a 330x28mm drilled two-piece rotor at the front axle, and a 345x12mm drilled two-piece oversized rotor at the rear, tied together with a set of TTSPORT stainless steel brake lines. Yellow calipers, gold drilled rotors — it's a kit that's meant to be seen through the spokes as much as it's meant to work.
Vehicle & Kit Specs
| Item | Specification |
|---|---|
| Vehicle | Lexus NX, factory 17-inch / 18-inch wheels |
| Front caliper | TTSPORT Classic 5440, four-piston, two-piece forged aluminum |
| Front rotor | TTSPORT 330mm x 28mm drilled two-piece rotor |
| Rear rotor | TTSPORT 345mm x 12mm drilled two-piece oversized rotor |
| Lines | TTSPORT stainless steel brake lines |
Here's the full official spec sheet for the TTSPORT 5440 caliper used in this build:
| Brake Caliper | |
|---|---|
| Series | Classic Series |
| Model / Application | 5440 |
| Axle Position | Front |
| Piston Count | 4-piston |
| Piston Type | Star-profile racing pistons without dust boots |
| Piston Diameter | 38 mm × 2 / 41 mm × 2 |
| Caliper Dimensions | L 276 mm × W 138 mm × H 80 mm |
| Total Piston Area | 49.1 cm² per caliper, all pistons combined |
| Manufacturing Process | Two-piece forged aluminum body |
| Net Weight | 2.65 kg per caliper, without pads |
| Surface Finish | High-temperature gloss coating |
| Recommended Wheel Size | 17 in or larger |
| Recommended Rotor Size | Ø330–345 mm × 28 mm |
| Fitment & Installation | |
| Minimum Spoke Clearance (mm) | 86 |
| Caliper Mounting Type | Radial mount with vehicle-specific caliper brackets |
| Brake Line Fitting Type | Vehicle-specific fittings; caliper-side and chassis-side fittings vary by application |
Why It Works
The TT5440 is a two-piece forged aluminum caliper rather than a single-piece casting, which means less flex under load — pedal effort goes into clamping the rotor instead of deforming the caliper body. Its four star-profile pistons (two 38mm, two 41mm) add up to 49.1cm² of piston area per side, spreading clamping force across the pad more evenly than a smaller factory caliper can.
Larger rotors matter too: the 330x28mm front and 345x12mm rear two-piece rotors carry more mass and surface area than the stock discs, so they absorb and shed more heat before fade sets in. And because the kit is sized to a minimum spoke clearance of 86mm and built around vehicle-specific brackets, it installs behind the Lexus NX's factory 17-inch and 18-inch wheels without spacers.
- Two-piece forged caliper body resists flex for a firmer, more consistent pedal
- Larger front and rear two-piece rotors add heat capacity to fight fade
- Clears the factory 17-in/18-in Lexus NX wheels with no spacers
Installation Gallery
What size wheels does the TTSPORT 5440 kit fit on the Lexus NX?
What's included in this TTSPORT big brake kit for the Lexus NX?
How many pistons does the TT5440 caliper use, and what's it made of?
Need fitment confirmation? Choose the closest TTSPORT series or send your vehicle, wheel size, and intended use before ordering.
