Honda Elysion Big Brake Kit Upgrade / TTSPORT Mono EMB6
Honda Elysion owners keep telling us the same thing: the pedal feels soft, travel is long, and under a hard stop the car shudders. That's a common complaint on this MPV's stock single-piston setup, and it's exactly the kind of problem a properly designed big brake kit is built to solve. This case swaps in TTSPORT's Mono Series EMB6 six-piston caliper up front, paired with an oversized 325mm rear rotor.
The owner's chief complaints were the usual soft-pedal symptoms: a long, spongy pedal stroke and noticeable shudder during hard braking. Rather than just refreshing worn stock parts, the goal here was a real upgrade — more clamping force, better heat management, and a firmer, more predictable pedal for daily driving and emergency stops alike.
Vehicle & Kit Specs
| Item | Specification |
|---|---|
| Vehicle | Honda Elysion, 19-inch wheels |
| Front caliper | TTSPORT Mono EMB6 forged monoblock six-piston caliper |
| Rear rotor | TTSPORT 325mm high-carbon oversized rotor |
| Bracket | Vehicle-specific caliper mounting bracket |
| Lines | TTSPORT stainless steel brake lines |
| Hardware | Brake fluid, mounting bolts, and installation hardware |
Here's the full official spec sheet for the EMB6 caliper used in this build:
| Brake Caliper | |
|---|---|
| Series | Mono Series |
| Model / Application | EMB6 |
| Axle Position | Front |
| Piston Count | 6-piston |
| Piston Type | Two-piece heat-insulated pistons without dust boots |
| Piston Diameter | 30 mm × 2 / 34 mm × 2 / 38 mm × 2 |
| Caliper Dimensions | L 382 mm × W 160 mm × H 92 mm |
| Total Piston Area | 55.0 cm² per caliper, all pistons combined |
| Manufacturing Process | Monoblock forged aluminum body |
| Net Weight | 3.25 kg per caliper, without pads |
| Surface Finish | Nickel-plated |
| Recommended Wheel Size | 18 in or larger |
| Recommended Rotor Size | Ø355–405 mm × 32 mm-34 mm |
| Fitment & Installation | |
| Minimum Spoke Clearance (mm) | 101 |
| Caliper Mounting Type | Radial mount with vehicle-specific caliper brackets |
| Brake Line Fitting Type | Vehicle-specific fittings; caliper-side and chassis-side fittings vary by application |
The complete kit for this Elysion covers a vehicle-specific caliper bracket, brake fluid, mounting bolts, and the fasteners needed for a bolt-on install — no cutting, no drilling.
Why It Works
- Monoblock forged construction with a through-brace design adds structural rigidity over a stock caliper, so the caliper flexes less under load and the pedal feels more direct.
- Six pistons (55.0 cm² of total piston area per caliper) spread clamping force across a larger pad footprint, generating more stopping force than a single-piston stock caliper for the same pedal input.
- Two-piece, heat-insulated pistons help manage seal temperatures under repeated hard stops, supporting a more linear, predictable pedal feel at speed.
- A lightweight, vented caliper body sheds heat faster, which helps limit fade on longer or repeated braking events.
- The larger 325mm rear rotor adds thermal mass at the back axle, balancing front-to-rear heat capacity as clamping force goes up.
- Installed under the owner's stock 19-inch wheels with a vehicle-specific bracket, keeping the swap a straightforward bolt-on.
Installation Gallery
FAQ
What wheel size does this Honda Elysion brake upgrade run?
What's included in the TTSPORT EMB6 kit for the Elysion?
How many pistons are in the EMB6 caliper, and how is it built?
Need fitment confirmation? Choose the closest TTSPORT series or send your vehicle, wheel size, and intended use before ordering.
