Honda Civic (10th Gen) Big Brake Kit Upgrade / TTSPORT Classic 5440
A lot of drivers get into brake upgrades for the first time by picking an imported brand without fully understanding what they're paying for — and that price premium usually comes from freight and import duties, not necessarily better hardware. When a first-round brake mod doesn't deliver the pedal feel or stopping power the owner expected, the next step is a second upgrade. That's exactly what happened with this 10th-generation Honda Civic, running 18-inch wheels, which moved to a TTSPORT 5440 setup after its previous brake parts fell short.
The build swapped in a complete TT front brake package: the TT5440 forged four-piston caliper, a TT Dacromet-coated rotor, and TT stainless steel brake lines. All three pieces went on together, replacing the car's previous aftermarket brake parts as a full front-end refresh rather than a partial swap.
Vehicle & Kit Specs
| Item | Specification |
|---|---|
| Vehicle | 10th-generation Honda Civic, 18-inch wheels |
| Front caliper | TTSPORT 5440 forged four-piston caliper |
| Front rotor | TT Dacromet-coated brake rotor |
| Bracket | Vehicle-specific radial-mount caliper bracket |
| Brake lines | TT stainless steel brake lines |
The table below is TTSPORT's official spec sheet for the 5440 caliper used in this install.
| Brake Caliper | |
|---|---|
| Series | Classic Series |
| Model / Application | 5440 |
| Axle Position | Front |
| Piston Count | 4-piston |
| Piston Type | Star-profile racing pistons without dust boots |
| Piston Diameter | 38 mm × 2 / 41 mm × 2 |
| Caliper Dimensions | L 276 mm × W 138 mm × H 80 mm |
| Total Piston Area | 49.1 cm² per caliper, all pistons combined |
| Manufacturing Process | Two-piece forged aluminum body |
| Net Weight | 2.65 kg per caliper, without pads |
| Surface Finish | High-temperature gloss coating |
| Recommended Wheel Size | 17 in or larger |
| Recommended Rotor Size | Ø330–345 mm × 28 mm |
| Fitment & Installation | |
| Minimum Spoke Clearance (mm) | 86 |
| Caliper Mounting Type | Radial mount with vehicle-specific caliper brackets |
| Brake Line Fitting Type | Vehicle-specific fittings; caliper-side and chassis-side fittings vary by application |
Why It Works
The 5440's two-piece forged aluminum body is stiffer and lighter than a cast caliper of similar size, which matters at the pedal: less caliper flex under clamping load means less of your pedal travel gets absorbed by the hardware instead of the pads. Four pistons — two 38mm, two 41mm — spread clamping force across a larger pad area than a smaller single- or twin-piston setup, for more even pad wear and a firmer bite.
The Dacromet coating on the rotor is a corrosion-resistant finish, which is also why the disc keeps its clean, uniform look longer than an untreated rotor. TTSPORT's spec calls for a 17-inch or larger wheel with the 5440, and this build ran it comfortably behind the Civic's 18-inch wheels.
- Forged two-piece caliper body for less flex under braking
- Four-piston layout spreads clamping force for a firmer pedal
- Stainless lines resist swelling for a more consistent pedal feel
- Fits behind the Civic's factory 18-inch wheels
Installation Gallery
What wheel size does the TTSPORT 5440 kit fit on this Civic?
What's included in this Civic brake upgrade?
Is the TT5440 caliper forged or cast?
Why does the rotor use a Dacromet coating?
