Product Detail
xRacing Series · Circuit · Rear Axle · 2-Piston
TR20 Rear 2-Piston Racing Big Brake Kit
The TR20 is a lightweight 2-piston rear racing caliper built for teams that need rear brake contribution to be consistent, measurable, and tunable. In a proper motorsport package, the rear axle is not judged by peak clamp alone — it has to support the front, hold bias, and keep the pad compound window usable across a full session.
Built around a two-piece forged aluminum body and racing pistons without dust boots, the TR20 is engineered for track, drift, rally, and endurance use where thermal repeatability and pedal consistency matter over repeated high-energy stops. Each kit is built through a vehicle-specific workflow so rear bias, rotor package, bracket geometry, brake line routing, and wheel clearance are confirmed before production.
Why Builders Choose the TR20
Rear-Axle Control
Built to support the front brake package, hold bias, and keep rear contribution predictable through a full session.
Thermal Repeatability
Ø330 mm × 25 mm two-piece vented rotor with directional vane pattern keeps stop-to-stop temperatures predictable through a session.
Race Pad Window
Open piston design without dust boots supports race pad operating ranges up to 600 °C standard or 750 °C with the Option B compound.
Serviceability
Two-piece forged construction, replaceable rotor rings, and standard race-pad shapes shorten paddock turnaround between sessions.
Vehicle-Specific Engineering
Rear bias, rotor package, bracket geometry, brake line routing, and wheel clearance are confirmed before production.
Technical Specifications & Kit Options
| Brake Caliper | ||
|---|---|---|
| Series | Racing Series — Circuit | |
| Model / Application | TR20 | |
| Axle Position | Rear | |
| Piston Count | 2-piston | |
| Piston Type | Racing pistons without dust boots | |
| Piston Diameter | 44.4 mm × 2 | |
| Caliper Dimensions | 182.3 mm × 148 mm × 71.6 mm | |
| Total Piston Area | 30.95 cm² per caliper, all pistons combined | |
| Manufacturing Process | Two-piece forged aluminum body | |
| Net Weight | 1.73 kg per caliper, without pads | |
| Surface Finish | Nickel-plated | |
| Custom Color | Not available on this caliper line | |
| Recommended Wheel Size | 17 in or larger | |
| Recommended Rotor Size | Ø330 mm × 25 mm | |
| Brake Rotor Options | ||
| Rotor Option | Standard | Option B |
| Rotor Material | Heat-treated high-carbon cast iron | Racing-grade heat-treated high-carbon cast iron |
| Axle Position | Rear | Rear |
| Rotor Dimensions | Ø330 mm × 25 mm | Ø330 mm × 25 mm |
| Construction | Two-piece rotor assembly | Two-piece rotor assembly |
| Ventilation | Internally vented | Internally vented |
| Rotor Hats | Application-specific alloy rotor hats | Application-specific alloy rotor hats |
| Rotor Mounting | Fixed or floating, depending on rotor size and vehicle application | Fixed or floating, depending on rotor size and vehicle application |
| Directional Design | Yes — left/right specific | Yes — left/right specific |
| Rotor Face Pattern | Curved slotted / Grain Slot / Wave Slot / Drilled and slotted | Wave Slot |
| Recommended Use | Steel rotor build for circuit, drift, rally, and endurance rear-axle control | Racing steel rotor build for higher peak energy events and heavier rear brake use |
| Brake Pad Options | ||
| Pad Option | Standard | Option B |
| Compatible Rotor Material | Iron / steel rotors only | Iron / steel rotors only |
| Operating Temperature Range | 0–600 °C | 0–750 °C |
| Average Friction Coefficient | μ ≈ 0.38; varies with temperature, line pressure, and rotor condition | μ ≈ 0.45; varies with temperature, line pressure, and rotor condition |
| Recommended Use | Track, drift, rally, and rear brake contribution in balanced motorsport packages | Endurance, downhill rally stages, heavy drift entries, and higher peak energy events |
| Lines, Brackets & Service | ||
| Brake Line Construction | Three-layer reinforced construction | |
| Brake Line Material | PTFE inner liner / SUS304 stainless-steel braid / PVC protective outer sheath | |
| Caliper Mounting | Radial mount with vehicle-specific caliper brackets | |
| Caliper Brackets | Vehicle-specific radial caliper brackets confirmed during the build workflow | |
| Rotor Hats | Application-specific alloy rotor hats matched to rear hub geometry and rotor offset | |
| Brake Line Fittings | Vehicle-specific; caliper-side and chassis-side fittings vary by application | |
| Wheel Clearance | 17 in wheels or larger; spoke profile is verified before production for race wheel sets | |
| Rotor Service | Two-piece rotor design allows friction ring replacement while retaining the alloy hat when serviceable | |
| Bedding-In Procedure | Required before pushing the system to race pace | |
Option B is intended for higher peak energy events — endurance, downhill rally stages, or heavy drift entries — where the standard pad would push past its window. Caliper finish is nickel-plated; color customization is not available on this caliper line.
Package List
Calipers ×2
2 × TR20 rear two-piece forged 2-piston calipers with nickel-plated finish.
Brake Pads
Brake pads for both rear calipers, selected from Standard 0–600 °C or Option B 0–750 °C compound.
Brake Rotors ×2
2 × two-piece internally vented rear rotors, Ø330 mm × 25 mm, left/right specific.
Caliper Brackets ×2
Vehicle-specific radial caliper brackets for correct rear caliper position and alignment.
Rotor Hats ×2
Application-specific alloy rotor hats matched to rear hub location and rotor offset.
Brake Hoses ×2
Three-layer stainless-steel braided rear brake lines with PTFE inner liner, SUS304 stainless-steel braid, and PVC protective outer sheath.
The Bespoke Engineering Process
Every TR20 rear racing system is engineered around the vehicle’s rear knuckle, hub location, rotor hat offset, wheel barrel, spoke clearance, brake line routing, front BBK pairing, rear bias target, axle role, and intended motorsport use. The goal is not a generic universal fit; the goal is a rear brake package that supports the front axle, holds bias, and gives the driver repeatable pedal behavior across a full session.
1. Technical Consultation
We review the vehicle, rear suspension and knuckle setup, axle role, current front brake setup, target bias, competition use, wheel package, tire compound, and whether the car uses OEM or custom rear uprights.
2. Data Submission
For OEM knuckles, provide vehicle details, current front brake setup, wheel size, wheel specs, and intended use. For custom rear uprights, provide CAD files, technical drawings, hub-face data, rotor mounting dimensions, or accurate bracket mounting-point measurements.
3. Engineering Review & Approval
TTSPORT confirms rear bias target, rotor option, pad compound, vehicle-specific caliper bracket geometry, rotor hat offset, brake line routing, and wheel clearance before the build is released.
If you are unsure whether your wheel, rear knuckle, front BBK pairing, rotor offset, brake line routing, or rear bias target is suitable, Contact us before ordering so the engineering team can review the build details.
Installation & Break-In
- Confirm vehicle, axle role, and front BBK pairing for the target rear bias.
- Verify 17 in or larger wheel fitment and spoke clearance against the TR20 caliper envelope.
- Lock bracket geometry, rotor offset, and brake line routing before production.
- TR20 rear kits ship with vehicle-specific caliper brackets, rotor hats, and braided rear lines.
- Use Standard pad and rotor specification for balanced rear contribution in circuit, drift, rally, and endurance packages.
- Use Option B for higher peak energy events where the rear brake package sees sustained heat.
- A proper bed-in procedure is required to seat the pad transfer layer before pushing the system to race pace.
Frequently Asked Questions
Is the TR20 a front or rear caliper?
The TR20 is a dedicated rear caliper — a 2-piston, 30.95 cm² platform sized to balance a larger front BBK without overbraking the rear axle.
What rotor size does it run?
Ø330 mm × 25 mm, two-piece, internally vented, directional left/right-specific. Available with standard high-carbon steel or racing-grade heat-treated steel.
What is the difference between the standard and Option B pad?
The standard pad runs 0–600 °C with μ ≈ 0.38. Option B extends the window to 0–750 °C at μ ≈ 0.45 for endurance, rally, and heavy drift work.
Will it clear my wheels?
17-inch wheels or larger are required. Spoke profile is verified against the caliper envelope during the build workflow before production starts.
Can I change the caliper color?
No. The TR20 ships nickel-plated and color customization is not offered on this race line.
Is bedding-in required?
Yes. A proper bed-in procedure is required to seat the pad transfer layer before pushing the system to race pace.
Spec Your TR20 Rear Kit
Send your vehicle, current front brake setup, wheel size, and intended use. Our engineering team will confirm rotor option, pad compound, bracket package, rotor hat offset, brake line routing, and wheel clearance before the build is released.
Care Guide
xBrake Kits · Fitment · Installation · Care Guide
Brake Kit Care Guide
A brake kit is not just a pair of larger calipers. Calipers, rotors, pads, hoses, brackets, rotor hats, mounting hardware, brake fluid, wheel clearance, and bedding procedure all work together as one system.
This guide explains how to confirm the right TTSPORT brake kit before ordering, what to check before installation, and how to care for the system after installation.
1. Before Ordering: Confirm the Full Vehicle Setup
Do not order a brake kit by vehicle name alone. The correct kit depends on the vehicle, axle position, wheel package, driving use, and brake system layout.
- Vehicle year, make, model, trim, market version, and chassis code if available
- Front or rear axle position
- Current brake rotor diameter, thickness, and caliper type if known
- Wheel diameter, width, offset, spoke shape, and inner barrel clearance
- Tire size and vehicle weight changes from armor, cargo, towing equipment, or track setup
- Driving use: daily street, towing, mountain driving, off-road, HPDE, rally, drift, track, or competition
- Whether the vehicle uses electronic parking brake, brake pad wear sensors, ABS / ESC systems, or special hydraulic routing
Brake kits are application-specific. A visually similar kit can still have the wrong rotor offset, bracket geometry, hose fitting, caliper position, or wheel clearance requirement.
2. Understand What Type of Brake Kit You Are Ordering
Different TTSPORT brake kit series use different hardware layouts. Always confirm what the kit includes before purchase.
Direct-Mount Kits
Use direct-mount calipers and one-piece rotors where specified. These kits do not use rotor hats or caliper brackets unless the final product page clearly states otherwise.
Two-Piece Rotor Kits
Use separate friction rings and rotor hats. Hat offset, ring bolt pattern, hardware style, and rotor direction must be matched correctly.
Racing / Custom Kits
May require bespoke brackets, rotor hats, brake lines, and engineering confirmation based on knuckle, hub, wheel, and competition use.
Off-Road / Heavy Vehicle Kits
Require extra attention to wheel clearance, tire size, vehicle load, descent control, hose routing, and dust / water exposure.
Do not assume every brake kit includes the same parts. Package contents vary by product series, vehicle application, and final order configuration.
3. Confirm the Kit Specification Before Payment
Before finalizing the order, review the kit specification carefully. Confirm the brake kit is matched to your vehicle and wheel setup, not only to the model name.
- Confirm vehicle application and axle position
- Confirm caliper model, piston count, and caliper color if applicable
- Confirm rotor diameter, rotor thickness, rotor construction, and left / right direction if applicable
- Confirm brake pad compound and intended use
- Confirm brake hose fitting type and routing compatibility
- Confirm whether caliper brackets, rotor hats, mounting hardware, wear sensors, or brake fluid are included
- Confirm minimum wheel diameter and spoke clearance requirement
- Confirm lead time, shipping method, and final invoice details
If any part is not listed in the final order or product page, do not assume it is included.
4. Before Installation: Inspect the Complete Kit
Inspect every component before installation. Do not modify, grind, drill, stretch, force, or space brake kit components to make them fit.
- Check all received parts against the order confirmation
- Inspect calipers, rotors, brackets, hats, hoses, pads, and hardware for shipping damage
- Confirm left / right caliper and rotor orientation where applicable
- Confirm rotor size, pad shape, hose fittings, bracket layout, and hardware style before installation
- Clean all mounting faces before assembly
- Confirm torque values, bedding procedure, fluid type, and bleeding procedure before starting work
- Use a qualified brake technician for installation
Safety: Brake kits affect braking force, hydraulic sealing, heat control, wheel clearance, and vehicle stability. Do not install the kit if fitment, torque, direction, clearance, or compatibility is unclear.
5. Installation Checks
Correct installation is as important as the brake kit itself. A properly engineered kit can still perform poorly if installed with dirty mounting faces, incorrect torque, poor hose routing, or trapped air in the hydraulic system.
Caliper Position
Verify caliper centering over the rotor and confirm even pad sweep across the friction surface.
Rotor Orientation
Confirm left / right rotor direction if the rotor uses directional vanes or directional face pattern.
Brake Hose Routing
Check brake hose length and routing at full steering lock and full suspension travel. No twisting, rubbing, stretching, or kinking.
Wheel Clearance
Check caliper-to-spoke and caliper-to-barrel clearance before road use. Wheel diameter alone is not enough.
Brake Fluid & Bleeding
Use the correct brake fluid type and bleed the system until pedal feel is firm and consistent.
Hardware Security
Torque all brake hardware to the specified value. Do not reuse damaged, unknown, stretched, or corroded safety-critical fasteners.
6. Bedding and First Heat Cycle
Brake pads and rotors need a controlled bedding process before full performance is available. Bedding helps create an even transfer layer on the rotor surface, improving bite, pedal consistency, and vibration resistance.
- Follow the bedding procedure supplied with the exact pad and rotor compound
- Use moderate heat first unless the supplied procedure requires otherwise
- Do not start with emergency stops on a fresh pad / rotor setup
- Avoid holding the brake pedal while stopped on very hot pads and rotors
- Allow the brakes to cool after bedding
- After the first heat cycle, inspect pad contact, rotor surface, hose routing, hardware security, and fluid leaks
Street pads, race pads, iron rotors, two-piece rotors, and carbon ceramic rotors may require different bedding procedures. Use the procedure supplied with the specific kit.
7. Initial Break-In Period
After installation and bedding, give the system a short break-in period before aggressive use. Pedal feel, pad contact, dust output, and noise may continue to settle after the first drives.
- Avoid repeated emergency stops unless required for safety
- Avoid hard track use until bedding and inspection are complete
- Monitor pedal feel, vibration, noise, smell, and rotor surface appearance
- Recheck for fluid leaks after the first road test
- Recheck torque where the kit instructions require post-heat-cycle inspection
- Contact TTSPORT if brake feel changes suddenly after installation
8. Routine Care and Inspection
Brake kits need regular inspection, especially after track use, off-road use, towing, mountain driving, winter salt exposure, or any brake service.
- Inspect brake pads for uneven wear, taper, glazing, cracking, or backing-plate damage
- Inspect rotors for cracks, heavy scoring, hot spots, minimum thickness, and runout
- Inspect calipers for fluid seepage, piston movement, dust boot damage, and uneven pad retraction
- Inspect brake hoses for rubbing, cuts, swelling, leaks, and fitting corrosion
- Inspect brackets, rotor hats, and mounting hardware for cracks, fretting, corrosion, or loosening
- Check brake fluid level, color, service age, and boiling-point suitability for your driving use
- Clean brake dust from wheels and calipers regularly, especially after wet, salty, or track conditions
9. Care by Use Case
Daily Street
Inspect pads, rotors, fluid level, and hose condition during normal service intervals. Prioritize quiet operation, smooth pedal feel, and even wear.
Towing & Mountain Roads
Check pad thickness, rotor surface condition, and fluid condition more often. Long descents create sustained heat even without track use.
Off-Road
Inspect for mud, sand, stone impact, hose abrasion, dust boot damage, and caliper contamination after trail use.
Track / HPDE
Inspect pads, rotors, fluid, and hardware before and after every event. Track heat shortens service intervals.
Drift / Competition
Check rear brake temperature, hydraulic handbrake behavior, pad wear, rotor cracking, and hardware condition frequently.
Carbon Ceramic
Use only compatible pads and approved bedding procedures. Inspect rotor surface condition carefully and avoid incompatible friction materials.
10. Stop Driving If You Notice These Symptoms
Do not continue driving if the brake system shows any of the following symptoms. Inspect the system or contact a qualified brake technician before using the vehicle again.
- Soft pedal, sinking pedal, or sudden increase in pedal travel
- Brake fluid leak or wetness near a line, caliper, fitting, or master cylinder
- Grinding, scraping, severe vibration, or heavy brake judder
- Vehicle pulling strongly to one side under braking
- Burning smell after light driving
- Loose wheel, rotor, caliper, bracket, or hardware noise
- Brake warning light, ABS warning light, or traction-control fault after brake work
Need help confirming brake kit setup or care?
Send your vehicle details, brake kit series, wheel specs, driving use, photos, and any symptoms you notice. TTSPORT will help confirm fitment, installation checks, and the correct care path for your brake kit.
- Choosing a selection results in a full page refresh.
