Nissan A31 Big Brake Kit Upgrade / TTSPORT Classic 5440
This 1988 Nissan A31 sees regular duty on the drift course, at gymkhana events, and in 0-400m sprints, and its owners at 380 Auto Club decided the stock brake hardware needed to catch up with everything else on the car. The fix was a full TTSPORT front-and-rear big brake package: TT5440 four-piston forged calipers up front on 330x28mm rotors, and a dual-caliper TT7700 setup at each rear corner - one circuit for the service brake, a second dedicated to the drift handbrake - all tucked behind the car's 18-inch wheels.
A Chassis Built for the Drift Scene
Introduced in 1988, the A31 was Nissan's mid-size FR sedan, sold in various markets under the Bluebird and Cefiro names. Three decades on, clean examples are getting harder to find, but a large parts supply, simple mechanicals, and rear-wheel drive kept it relevant with drift and gymkhana builders long after Nissan moved on. Photos here are courtesy of 380 Auto Club, a China-based drift and car-meet club founded by veteran drift driver Gu Lixing. This particular A31 wears a Bosozoku-inspired body over drift-ready mechanicals, including a lowered stance paired with 18-inch wheels.
Vehicle & Kit Specs
| Item | Specification |
|---|---|
| Vehicle | Nissan A31 (Bluebird / Cefiro), 18-inch wheels |
| Front caliper | TTSPORT Classic Series 5440, forged four-piston |
| Front rotor | 330x28mm high-carbon heat-treated rotor |
| Rear caliper | TTSPORT 7700, dual two-piston calipers per corner (service brake + handbrake/drift circuit) |
| Rear rotor | 330x24mm high-carbon heat-treated rotor |
| Lines | TTSPORT stainless steel braided brake lines, rear |
The front caliper on this build is TTSPORT's Classic Series 5440. Full spec sheet for that unit below:
| Brake Caliper | |
|---|---|
| Series | Classic Series |
| Model / Application | 5440 |
| Axle Position | Front |
| Piston Count | 4-piston |
| Piston Type | Star-profile racing pistons without dust boots |
| Piston Diameter | 38 mm × 2 / 41 mm × 2 |
| Caliper Dimensions | L 276 mm × W 138 mm × H 80 mm |
| Total Piston Area | 49.1 cm² per caliper, all pistons combined |
| Manufacturing Process | Two-piece forged aluminum body |
| Net Weight | 2.65 kg per caliper, without pads |
| Surface Finish | High-temperature gloss coating |
| Recommended Wheel Size | 17 in or larger |
| Recommended Rotor Size | Ø330–345 mm × 28 mm |
| Fitment & Installation | |
| Minimum Spoke Clearance (mm) | 86 |
| Caliper Mounting Type | Radial mount with vehicle-specific caliper brackets |
| Brake Line Fitting Type | Vehicle-specific fittings; caliper-side and chassis-side fittings vary by application |
Why It Works
- The 5440 body is forged from aluminum alloy under roughly 3,000 tons of press force rather than cast, giving it more rigidity and less flex under hard, repeated braking than a cast caliper of similar size.
- Opposed racing-grade pistons and a slim caliper profile keep the unit compact enough to clear 18-inch wheels without spacers.
- Imported seals help manage heat at the piston bores, which keeps the pedal consistent and cuts down on brake noise during sustained use.
- Running two independent TT7700 calipers per rear wheel separates service braking from the handbrake circuit, letting the driver lock the rears on demand without touching front brake pressure - the same layout used on many purpose-built drift cars.
Installation Gallery
FAQ
What does the TTSPORT front brake kit on this Nissan A31 include?
Why does the rear axle run two calipers per side?
What wheel size does this A31 build run with the big brake kit installed?
Need fitment confirmation? Choose the closest TTSPORT series or send your vehicle, wheel size, and intended use before ordering.
