AITO M9 Big Brake Kit Upgrade / TTSPORT Evolution EB10
As EV and hybrid platforms get heavier and quicker off the line, their brakes have to work harder — more battery mass to slow down, more torque to arrest. Most of these vehicles still roll off the line with a 4-piston front caliper, which is fine for daily driving but starts to fade under repeated hard stops. This AITO M9 owner drives aggressively and wanted a setup that could hold a consistent, linear pedal through back-to-back stops — so he went with TTSPORT's Evolution Series front-and-rear kit: EB10 up front, EP4S in the rear.
The finished install: a forged 10-piston EB10 caliper and 420mm high-carbon rotor tucked behind the M9's stock 22-inch wheel, no visual compromise and a noticeably firmer pedal.
Vehicle & Kit Specs
Here's the full breakdown of what went on the car — front and rear axles, both ends built around TTSPORT's Evolution Series hardware.
| Item | Specification |
|---|---|
| Vehicle | AITO M9, 22-inch factory wheels |
| Front caliper | TTSPORT EB10 — forged 10-piston fixed caliper |
| Front rotor | TTSPORT 420mm high-carbon two-piece rotor |
| Rear caliper | TTSPORT EP4S electromechanical caliper — 4 hydraulic pistons plus integrated EPB actuator |
| Rear rotor | TTSPORT 380mm high-carbon rotor |
| Bracket | Custom vehicle-specific front and rear caliper brackets |
| Pads / lines | TTSPORT high-performance brake pads, stainless steel brake lines |
| Hardware | Brake fluid, mounting bolts and fitting hardware |
Below is the official TTSPORT spec sheet for the front EB10 caliper.
| Brake Caliper | |
|---|---|
| Series | Evolution Series |
| Model / Application | EB10 |
| Axle Position | Front |
| Piston Count | 10-piston |
| Piston Type | Two-piece heat-insulated pistons with dust boots |
| Piston Diameter | 28 mm × 4 / 30 mm × 6 |
| Caliper Dimensions | L 415 mm × W 168 mm × H 129 mm |
| Total Piston Area | 67.0 cm² per caliper, all pistons combined |
| Manufacturing Process | Two-piece forged aluminum body |
| Net Weight | 7.50 kg per caliper, without pads |
| Surface Finish | High-temperature gloss coating |
| Recommended Wheel Size | 20 in or larger |
| Recommended Rotor Size | Ø420–440 mm × 40 mm |
| Fitment & Installation | |
| Minimum Spoke Clearance (mm) | 108 (inner-rotor-to-inner-spoke distance) |
| Caliper Mounting Type | Radial mount with vehicle-specific caliper bracket |
| Brake Line Fitting Type | OEM-style chassis-side fitting |
And the official spec sheet for the rear EP4S electromechanical caliper.
| Brake Caliper | |
|---|---|
| Series | Evolution Series |
| Model / Application | EP4S |
| Axle Position | Rear |
| Piston Count | 4 hydraulic pistons + 1 for EPB actuator |
| Piston Type | 2-piece heat-insulated pistons with dust boots + EPB actuator |
| Piston Diameter | 28 mm × 4 / 27 mm × 1 |
| Caliper Dimensions | L 278 mm × W 202 mm × H 93 mm |
| Total Piston Area | 30.4 cm² per caliper, all pistons combined |
| Manufacturing Process | Two-piece forged aluminum body |
| Net Weight | 4.50 kg per caliper, without pads |
| Surface Finish | High-temperature gloss coating |
| Recommended Wheel Size | 18 in or larger |
| Recommended Rotor Size | Ø345–380 mm × 28 mm |
| Fitment & Installation | |
| Minimum Spoke Clearance (mm) | 97 |
| Caliper Mounting Type | Radial mount with vehicle-specific caliper brackets |
| Brake Line Fitting Type | Vehicle-specific fittings; caliper-side and chassis-side fittings vary by application |
Why It Works
Why the EB10 Front Caliper Works
The EB10 is a two-piece forged caliper built for heavy sedans, SUVs, and MPVs — including EVs with extra curb weight to shed. Its 10 pistons are laid out symmetrically so clamping force spreads evenly across the pad, which is what gives it a light, linear pedal at low effort and a hard, confident bite when you really stand on it. TTSPORT reinforces the caliper body with through-caliper ribbing that adds 20-30% more strength versus a conventional design, and the two-piece heat-insulated pistons with high-temp seals and dust boots keep clamping force stable as things heat up — including with carbon-ceramic rotors.
- Forged fixed-caliper body resists flex under hard braking, so pedal travel stays consistent instead of going long and soft after repeated stops.
- Larger 420mm front / 380mm rear rotors add mass and surface area, giving the system more heat capacity before fade sets in.
- The rear EP4S keeps the electronic parking brake fully functional — its dedicated actuator piston handles EPB duty independently of the four service-brake pistons.
- Custom-fit brackets locate both calipers to clear the M9's stock 22-inch wheels with no spacer workarounds.
